Feeders
144-D FEEDER
- Capacity: 5-50 Tons per Day.
- SG & DG 3" or 4 3/8" c.d. Operation.
- Standard or Deep Spout Casing.
- Differential Adjustment Range: 48°
- Tube Ø: 5", 6", 7" or 8"
194 FEEDER
- Capacity: 45-70 Tons per Day.
- SG & DG 4 3/8" c.d. Operation.
- Deep Spout Casing.
- Differential Adjustment Range: 48°
- Tube Ø: 7" or 8"
881-144 FEEDER
- Capacity: 5-50 Tons per Day.
- SG & DG 3" or 4 3/8" c.d. Operation.
- Standard or Deep Spout Casing.
- Differential Adjustment Range: 360°
- Type 81 Mechanism Box
- Type 144 Shear Box.
- Tube Ø: 5", 6", 7" & 8".
881-194 FEEDER
- Capacity: 45-70 Tons per Day.
- SG & DG 4 3/8" c.d. Operation.
- Standard or Deep Spout Casing.
- Differential Adjustment Range: 360°
- Tube Ø: 7" or 8"
881 FEEDER
-
Capacity: 5-75 Tons per Day.
-
SG & DG 4 3/8" c.d. Operation.
-
Standard or Deep Spout Casing.
-
Differential Adjustment Range: 360°
-
Tube Ø: 7" or 8"
803 FEEDER
-
Capacity: 35-90 Tons per Day.
-
SG & DG 4 3/8" c.d. Operation.
-
Deep Spout Casing.
-
Differential Adjustment Range: 360°
-
Tube Ø: 10" Standard or Autocentering
815 FEEDER
LEFT & RIGHT 144-D FEEDER
-
Capacity: 5-50 Tons per Day.
-
SG & DG 4 3/8" c.d. Operation.
-
Standard or Deep Spout Casing.
-
Differential Adjustment Range: 48°
-
Tube Ø: 8"
